A wire cut cookie machine is a dough forming machine that portions high-fat cookie dough through shaped dies and slices each piece with a reciprocating steel wire — the standard way to produce chocolate chip cookies, butter cookies, and chunky dough recipes with inclusions.
It solves the core challenge for bakeries and cookie factories: producing rustic, home-style cookies with consistent weight at industrial speed.
Wanttone wire cut cookie machines are available from compact tray-type models for small bakeries to fully automatic, 1,500 mm-wide units that integrate directly into a tunnel oven cookie production line. Servo-driven rollers and pumps, touch-screen recipe control, and quick-release die assemblies keep weight deviation within ±4% while reaching up to 100 cuts per minute.
Up to 100 cutting strokes per minute (and 100 strip cuts per minute), matching the output of full-length tunnel oven lines.
Precision pump feeding delivers a weight deviation of only ±4% (checked every 5 cookies) with a qualified rate of 98%, cutting giveaway and rework.
Purpose-built for rich dough with chocolate chips, nuts, raisins, and other particulates that ordinary depositors cannot portion cleanly.
Groove roller speed, pump feed rate, and cutting speed are set digitally on the HMI, making changeovers fast and operator skill requirements low.
Machine head side plates and connecting plates in 7075 aluminum alloy with Teflon treatment; pump teeth in food-grade POM; dies and rollers in SUS304 stainless steel.
Worm-gear clamping and eccentric-wheel die locks release with a handwheel turn, so dies and pump assemblies come off in minutes for washing.
Mini tray-type models from 400 mm up to large-scale one-color or two-color machines at 1,500 mm working width.
Confirm the incoming material or product condition, target throughput, infeed height and available utilities.
Up to 100 cutting strokes per minute (and 100 strip cuts per minute), matching the output of full-length tunnel oven lines.
Match discharge height, line speed, control signals, guarding and cleaning access with the next operation.
| Item | Mini Tray Type (400/600) | Industrial Series (800–1500) |
|---|---|---|
| Working Width | 400 / 600 mm | 800–1,500 mm |
| Forming Method | Wire cutting | Wire cutting / strip cutting |
| Max Cutting Speed | 100 cuts/min | 100 cuts/min |
| Weight Deviation | ±4% (per 5 cookies) | ±4% (per 5 cookies) |
| Qualified Rate | 98% | 98% |
| Installed Power | Approx. 4–6 kW | 6–12.5 kW |
| Dimensions (L×W×H) | 1,500×1,200/1,400×1,200 mm | Per model (customizable) |
| Machine Weight | 0.6–0.8 T | Per model |
| Power Supply | 380 V/50 Hz (customizable) | 380 V/50 Hz (customizable) |
Throughput (kg/h) depends on cookie weight and oven length; capacities of 150–500 kg of dough per hour are typical. Custom die shapes are available.
A wire cut cookie machine is only as good as its understanding of dough. Wanttone’s unique dual strength — manufacturing cookie equipment and running our own cookie production lines — means our wire cut machines are tuned against real recipes, including chocolate chip and butter cookies produced in our own factory. Backed by 40+ years of biscuit machinery heritage since 1981, an in-house research institute, and ISO 9001-controlled production, we supply not just a machine but a verified process: recipe support, die design, commissioning, operator training, and lifetime technical service from one accountable partner.
It portions stiff, high-fat cookie dough through shaped dies and cuts each portion with a steel wire — perfect for chocolate chip, oatmeal, nut, and butter cookies, including dough with large inclusions.
The pump-fed forming system keeps weight deviation within ±4% (weighed every 5 cookies), with a qualified product rate of 98%.
Yes. Wire cutting is specifically suited to chunky dough. The dies and wire mechanism are designed to portion dough with chips, nuts, and dried fruit without smearing.
Simply swap the die plate. Eccentric-wheel clamps release the die assembly quickly, and custom die shapes can be manufactured to your product design.
Yes. Industrial models are designed for in-line installation ahead of steel belt or mesh band tunnel ovens, with line speed synchronized to oven length and baking time.
