Automatic Feeding, Stacking & Packing Line

An automatic feeding, stacking and packing line takes unordered products arriving from the cooling section — Swiss rolls, sliced bread, biscuits, cookies, or cakes — and automatically aligns, counts, groups, and stacks them before feeding them into flow wrappers, on-edge packers, or cartoners at full rated speed.

Request Equipment Advice Talk to an Engineer
Reference illustration of Automatic Feeding, Stacking & Packing Line

Product Overview

The Wanttone automatic feeding, stacking and packing line replaces manual loading between production and packaging with servo-driven, product-gentle automation, turning a labor-intensive bottleneck into a continuous, synchronized flow that keeps every downstream packaging machine running at its designed output.

Biscuit stacking machine for downstream packing feed
Biscuit stacking equipment
Close view of the biscuit stacker's alignment and transfer section
Alignment and transfer detail

Capabilities & Applications

Key Features

  • Automatic Alignment & Grouping

    Servo-driven belts, guides, and star-wheel or lug-chain mechanisms convert a scattered product flow into aligned, counted groups without operator intervention.

  • Gentle Handling of Soft Products

    Low-impact transfer design handles Swiss rolls, sliced bread, and soft cakes without deformation, and fragile biscuits without chipping or breakage.

  • Modular Packing Connections

    The line feeds flow packing machines, on-edge packing machines, or cartoning systems, and can be reconfigured as your product range and pack formats grow.

  • Labor Reduction & Stable Output

    One automated line replaces several manual loading positions, delivering consistent pack counts and orientation across every shift regardless of operator skill.

  • Full-Line Speed Synchronization

    PLC control synchronizes feeding, stacking, and packing with upstream cooling conveyors and downstream wrappers, eliminating gaps, surges, and jams.

  • Hygienic Food-Grade Build

    Stainless-steel frames and food-contact parts with an open, accessible design support fast cleaning and compliance with food-safety audits.

  • Recipe-Based Changeover

    Product parameters — count per pack, grouping pattern, belt speeds — are stored and recalled per SKU for fast, repeatable changeovers.

Applications

  • The feeding, stacking and packing line is the bridge between baking and packaging in industrial bakeries and biscuit plants. Typical applications include Swiss roll multi-packs, sliced bread and loaf grouping, biscuit slug and tray formats, cookie collation for family packs, and cake bar wrapping. It is the natural downstream partner of Wanttone’s biscuit processing systems, and integrates with our flow packing machines, on-edge packing machines, and third-party wrappers.

A Defined Role in the Line

  1. Upstream Requirements

    Confirm the incoming material or product condition, target throughput, infeed height and available utilities.

  2. Core Machine Function

    Servo-driven belts, guides, and star-wheel or lug-chain mechanisms convert a scattered product flow into aligned, counted groups without operator intervention.

  3. Downstream Integration

    Match discharge height, line speed, control signals, guarding and cleaning access with the next operation.

Specifications & Configuration

Technical Parameters for Automatic Feeding, Stacking & Packing Line
ItemSpecification (typical range, customizable)
FunctionAutomatic feeding, alignment, counting, stacking, packing-machine feeding
ProductsSwiss rolls, sliced bread, biscuits, cookies, cakes, cake bars
Feeding systemServo-driven belts / star wheel / lug chain (per product)
Stacking formatCountable groups, slugs, multi-row patterns (per pack design)
Downstream interfaceFlow wrapper / on-edge packer / cartoner
ControlPLC with HMI; recipe storage; full-line synchronization
ConstructionFood-grade stainless steel contact parts

Layout, speed, and stacking pattern are engineered to your product and pack format — contact us for a configured line proposal.

The Wanttone Difference

This is where Wanttone’s one-stop capability delivers its full value. We design and build complete biscuit and bakery lines — from dough mixing and forming through baking, cooling, chocolate processing, and packing — so our feeding, stacking and packing lines are engineered from day one to synchronize with everything upstream. Wanttone’s own product range includes dedicated biscuit processing systems, and our own biscuit factory runs automated stacking and packaging daily, giving our engineers real production insight into product fragility, pack formats, and line balancing. With 40+ years of equipment engineering since 1981, ISO 9001 manufacturing, whole-plant layout design, on-site installation and commissioning, operator training, and lifetime after-sales support, you get a complete packaging solution from one accountable supplier.

Frequently Asked Questions

What products can the line handle?

Swiss rolls, sliced bread, biscuits, cookies, cakes, and cake bars. The feeding and stacking mechanism is selected and configured for your product’s size, shape, and fragility.

Can it feed different packing machine types?

Yes. The line is modular and can feed flow packing machines, on-edge packing machines, or cartoners. We configure the interface during line design.

How does the line handle soft products like Swiss rolls without deforming them?

Transfers are engineered for low impact — controlled drops, matched belt speeds, and gentle guides — so soft bakery products keep their shape and surface quality through stacking.

Can the stacking pattern and count per pack be changed?

Yes. Counts and grouping patterns are set per recipe on the PLC and recalled at changeover, with simple mechanical adjustments where product size changes significantly.

Will it synchronize with my existing production line?

Yes. We match conveyor heights, working widths, and speeds so the packing line integrates with existing cooling sections and wrappers, on Wanttone or third-party lines.
